DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
249
Parameter Description
IPv6 Address/Prefix Length
Enter the IPv6 address that will be used for these results here.
Click the Find button to locate a specific entry based on the information entered.
OSPF
OSPFv2
OSPFv2 Process Settings
This window is used to display and configure the OSPFv2 process settings.
To view the following window, click L3 Features > OSPF > OSPFv2 > OSPFv2 Process Settings, as shown below:
Figure 6-48 OSPFv2 Process Settings Window
The fields that can be configured in OSPF Process Settings are described below:
Parameter Description
VRF Name
Enter the name of the VRF instance here. This name can be up to 12 characters
long. Click the Select VRF button to select a pre-configured VRF instance that will
be used here.
Click the Find button to locate a specific entry based on the information entered.
Click the Show All button to display all the available entries.
Click the Edit button to modify the specified entry.
Click the Show Detail button to view more detailed information associated with the entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
After clicking the Select VRF button, the following page will appear.
Figure 6-49 OSPFv2 Process Settings (Select VRF) Window
