DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
361
To view the following window, click L3 Features > BGP > BGP Neighbor > Neighbor Map Settings, as shown below:
Figure 6-205 Neighbor Map Settings Window
The fields that can be configured are described below:
Parameter Description
Address Family
Select the address family that will be used here. Options to choose from are:
• IPv4 Unicast - Specifies to configure the BGP neighbor map settings related
to the IPv4 unicast address family.
• IPv4 VRF - Specifies to configure the BGP neighbor map settings related to
the VRF instance in the IPv4 address family. Enter the name of the VRF
instance here. This name can be up to 12 characters long. Alternatively, click
the Please Select button to select a pre-configured VRF instance that will be
used here.
• IPv4 Multicast - Specifies to configure the BGP neighbor map settings
related to the IPv4 multicast address family.
• L2VPN VPLS - Specifies to configure the BGP neighbor map settings related
to the Layer 2 VPN VPLS address family.
• VPNv4 - Specifies to configure the BGP neighbor map settings related to the
VPNv4 address family.
• IPv6 Unicast - Specifies to configure the BGP neighbor map settings related
to the IPv6 unicast address family.
Neighbor
Select and enter the BGP neighbor here. Options to choose from are:
• IPv4 Address - Enter the IPv4 address of the BGP neighbor here.
• Peer Group - Enter the name of the peer group of the BGP neighbor here.
This name can be up to 16 characters long.
• IPv6 Address - Enter the IPv6 address of the BGP neighbor here.
Unsupress Map Action
Select the unsuppress action that will be taken here. This is used to selectively
advertise routes that were previously suppressed by the aggregate address
feature. Options to choose from are Add and Delete.
Unsupress Map Name
Enter the name of the route map that will be unsuppressed here. This name can
be up to 16 characters long.
Route Map Type
Select the route map type here. Options to choose from are:
• In - Specifies a route map that was applied to paths advertised from the
neighbor.
• Out - Specifies a route map that was applied to the paths advertised to the
neighbor.
Route Map Action
Select the route map action here. Options to choose from are Add and Delete.
Route Map Name
Enter the name of the route map here. This name can be up to 16 characters
