DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
197
The fields that can be configured in Member Port Settings are described below:
Parameter Description
VID
Enter the multicast VLAN ID that will be used here. The range is 2 to 4094.
Action
Select Add to add a new entry based in the information entered.
Select Delete to delete an entry based in the information entered.
Role
Select the role here. Options to choose from are Receiver and Source.
• Receiver - Specifies to configure the port as a subscriber port that can only
receive multicast data in the multicast VLAN.
• Source - Specifies to configure the port as an uplink port that can send
multicast data in the multicast VLAN.
Type
Select the type here. Options to choose from are Tagged and Untagged.
• Tagged - Specifies that if a port is a tagged member, the packets sent from
the port are tagged with the Multicast VLAN ID.
• Untagged - Specifies that if the port is an untagged member, then the
packets will be forwarded in the untagged form.
Unit
Select the Switch unit ID that will be used here.
From Port - To Port
Select the Switch port range that will be used here.
Click the Apply button to accept the changes made.
The fields that can be configured in Replace Priority Settings are described below:
Parameter Description
VID
Enter the multicast VLAN ID that will be used here. The range is 2 to 4094.
Action
Select Add to add a new entry based in the information entered.
Select Delete to delete an entry based in the information entered.
IP Type
Select the IP type here. Options to choose from are IPv4 and IPv6.
• IPv4 - Specifies to the remap priority for IPv4 multicast packets forwarded on
the multicast VLAN.
• IPv6 - Specifies to the remap priority for IPv6 multicast packets forwarded on
the multicast VLAN.
Priority
Select the priority value here. The range is from 0 to 7. A lower value represents a
higher priority.
Click the Apply button to accept the changes made.
The fields that can be configured in Replace Source IP Settings are described below:
Parameter Description
VID
Enter the multicast VLAN ID that will be used here. The range is 2 to 4094.
Action
Select Add to add a new entry based in the information entered.
Select Delete to delete an entry based in the information entered.
Address Type
Select the address type here. Options to choose from are IPv4 and IPv6.
• IPv4 - Specifies to enter the source IPv4 address for IGMP control packet
reporting up to routers.
• IPv6 - Specifies to enter the source IPv6 address for MLD control packet
reporting up to routers.
IP Address
Enter the IPv4/IPv6 address here.
