DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
340
To view the following window, click L3 Features > BGP > BGP Dampening Settings, as shown below:
Figure 6-178 BGP Dampening Settings Window
The fields that can be configured in BGP Dampening are described below:
Parameter Description
Address Family
Select the address family that will be used here. Options to choose from are:
• IPv4 Unicast - Specifies to use the IPv4 unicast address family in this
configuration.
• IPv4 VRF - Specifies to use a VRF instance in this configuration. Enter the
name of the VRF instance in the space provided or click the Please Select
button to select a pre-configured VRF instance that will be used here. This
name can be up to 12 characters long.
• IPv4 Multicast - Specifies to use the IPv4 multicast address family in this
configuration.
• IPv6 Unicast - Specifies to use the IPv6 unicast address family in this
configuration.
The fields that can be configured in BGP Dampening State are described below:
Parameter Description
Dampening State
Select to enable or disable the BGP dampening state here.
Click the Apply button to accept the changes made.
The fields that can be configured in BGP Dampening Route Map are described below:
Parameter Description
BGP Dampening Route Map
Enter the BGP dampening route map name here. This name can be up to 16
characters long
Click the Apply button to accept the changes made.
The fields that can be configured in BGP Dampening Settings are described below:
Parameter Description
Half Life Time
Enter the half-life time value here. This specifies the time after which the
accumulated penalty of the route is decreased by half. The range is from 1 to 45
