DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
434
Click the Delete button, next to the ACL rule, to remove the specific ACL rule.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
After clicking the Edit button, the following page will appear.
Figure 8-9 ACL Access List (Edit) Window
After clicking the Edit button, the fields that can be configured are described below:
Parameter Description
Start Sequence No.
Enter the start sequence number here.
Step
Enter the sequence number step here. The step range is from 1 to 32. This
specifies the number that the sequence numbers step. The default value is 10.
For example, if the increment (step) value is 5 and the beginning sequence
number is 20, the subsequent sequence numbers are 25, 30, 35, 40, and so on.
Counter State
Select to enable or disable the counter state option here.
Remark
Enter an optional remark that will be associated with this ACL here.
Click the Apply button to accept the changes made.
After clicking the Add ACL button, the following page will appear.
Figure 8-10 ACL Access List (Add ACL) Window
After clicking the Add ACL button, the fields that can be configured are described below:
Parameter Description
ACL Type
Select the ACL type that will be created here. Options to choose from are
To Next Page
