Ducati ST3 2004 User Manual

Uso e manutenzione
Maintenance operations
sezione / section
D 5
43
A
B
C
D
E
F
G
H
L
M
N
P
ST3 - M.Y. 2004 - edizione/edition 00
5 - STRUMENTI DI DIAGNOSI
1 590.1.190.1A Tubo pressione carburante
2 514.1.034.1A Cavo alimentazione e
diagnosi PFA621
3 552.1.039.1A Sensore pressione
4 814.1.114.1A Raccordo pressione olio
5 514.1.032.1A Cavo per prove ausiliari
6 552.1.037.1A Cavo compressione cilindri
attacco M12
7 875.1.065.1A Tubo pressione olio
5 - DIAGNOSTIC INSTRUMENTS
1 590.1.190.1A Fuel pressure hose
2 514.1.034.1A PFA621 power and
diagnostics cable
3 552.1.039.1A Pressure sensor
4 814.1.114.1A Oil pressure union
5 514.1.032.1A Auxiliary test cable
6 552.1.037.1A Cylinder compression
hose, M12 thread
7 875.1.065.1A Oil pressure hose
2
3
4
5
6
7
1
