Impianto iniezione - accensione
Ignition - injection system
sezione / section
M 2
12 ST3 - M.Y. 2004 - edizione/edition 00
Legenda schema iniezione -
accensione
1 Fusibili iniezione
2 Motorino avviamento
3 Teleruttore avviamento
4 Batteria
5 Serbatoio
6 Connessione autodiagnosi
7 Candela cilindro orizzontale
8 Candela cilindro orizzontale
9 Bobina cilindro orizzontale
10 Candela cilindro Verticale
11 Candela cilindro Verticale
12 Bobina cilindro Verticale
13 Iniettore cilindro Orizzontale
14 Iniettore cilindro Verticale
15 Potenziometro farfalla
16 Sensore giri/fase
17 Sensore temperatura acqua
18 Sensore velocità veicolo
19 Interruttore stampella laterale
20 Interruttore folle
21 Interruttore pressione
22 Unita' accensione/iniezione
23 Rele' iniezione
24 Sensore temperatura aria
25 Cruscotto
26 Interruttore frizione
27 Commutatore destro
28 Commutatore a chiave
29 Scatola fusibili
30 Connessione di sgancio
Legenda fusibili
a Alimentazione centralina (3 A)
b Iniezione (20 A)
c Presa di corrente (20 A)
Codici colore cavi schema
iniezione - accensione
B Blu
W Bianco
V Viola
Bk Nero
Y Giallo
R Rosso
Lb Azzurro
Gr Grigio
G Verde
Bn Marrone
O Arancio
P Rosa
Injection - ignition system
diagram legend
1 Injection fuses
2 Starter motor
3 Starter switch
4 Battery
5Tank
6 Autodiagnostics connector
7 Horizontal cylinder spark plug
8 Horizontal cylinder spark plug
9 Horizontal cylinder coil
10 Vertical cylinder spark plug
11 Vertical cylinder spark plug
12 Vertical cylinder coil
13 Horizontal cylinder injector
14 Vertical cylinder injector
15 Throttle potentiometer
16 Engine speed/timing sensor
17 Coolant temperature sensor
18 Road speed sensor
19 Side stand switch
20 Neutral switch
21 Pressure sensor
22 Ignition/injection control unit
23 Injection relay
24 Air temperature sensor
25 Instrument panel
26 Clutch switch
27 Right switch group
28 Ignition key switch
29 Fuse box
30 Connector
Fuses legend
a Control unit power (3 A)
b Injection system (20 A)
c Power socket (20 A)
Injection - ignition system
wiring diagram colour scheme
B Blue
W White
V Violet
Bk Black
Y Yellow
R Red
Lb Light blue
Gr Grey
G Green
Bn Brown
O Orange
P Pink
