ST3 - M.Y. 2004 - edizione/edition 00
Product specifications
Symbols inside the diagram show the type of threadlocker, sealant or lubricant to be used at the points indicated. The table below
shows the symbols together with the specifications for the threadlockers, sealants and lubricants to be used.
Symbol Specifications Recommended product
Engine oil (for specifications, see sect. C 2). SHELL
Advance Ultra 4
DOT 4 special hydraulic brake fluid. SHELL
Advance Brake DOT 4
SAE 80-90 gear oil or special products for chains
with O-rings.
SHELL
Advance Chain o Advance Teflon Chain
Anti-freeze (nitride, amine and phosphate free)
30-40% water solution.
SHELL
Advance coolant o Glycoshell
GREASE A Multipurpose, medium fiber, lithium grease. SHELL Alvania R3
GREASE B Molybdenum disulphide grease, high mechanical
stress and high temperature resistant.
SHELL
Retinax HDX2
GREASE C Bearing/joint grease for parts subject
to prolonged mechanical stress.
Temperature range: -10 to 110° C.
SHELL
Retinax LX2
GREASE D Protective grease. Corrosion protectant,
waterproof.
SHELL
Retinax HD2
GREASE E PANKL grease PLB 05.
GREASE F OPTIMOL grease PASTE WHITE T.
LOCK 1 Low-strength threadlocker. Loctite 222
LOCK 2 Medium-strength threadlocker, compatible with
oil.
Loctite 243
LOCK 3 High-strength sealant for threaded parts. Loctite 270
LOCK 4 Flange sealant. Resistant to high mechanical
stress, solvents and high temperatures (up to
200°C). For pressures up to 350 atm. Fills gaps
up to 0.4 mm.
Loctite 510
LOCK 5 Permanent adhesive for smooth or threaded
cylindrical fasteners on mechanical parts. High
resistance to mechanical stress and solvents.
Temperature range: -55 to 175°C.
Loctite 128455
LOCK 6 Pipe sealant for pipes and medium to large
fasteners. For water and gases (except oxygen).
Maximum filling capacity: diameter gaps up to
0.40 mm.
Loctite 577
A
B
C
D
E
F
1
LOCK
2
LOCK
3
LOCK
4
LOCK
5
LOCK
6
LOCK
