Caratteristiche tecniche
Technical specification
sezione / section
C 1.1
10
A
B
C
D
E
F
G
H
L
M
N
P
ST3 - M.Y. 2004 - edizione/edition 00
1.1 - TECHNICAL DATA
Description
Reference Technical specifications
Vehicle dimensions Total length 2070 mm
Total width 906 mm
Total height 1274 mm
Wheelbase 1430 mm
Handlebar height from 910 to 930 mm
Seat height 820mm
Front footpeg height 370 mm
Rear footpeg height 535 mm
Min. ground clearance 165 mm
Dry weight 214 kg
Weight with full load not over 420 kg
Frame Type ALS 450 steel tube trellis frame
Steering head angle 24°
Steering angle 30° RH and LH
Trail 102 mm
Front rim light alloy, three spokes
Front rim size MT 3.50 x 17"
Front tyre 120/70 - ZR 17"
Rear rim light alloy, three spokes, transmission dampers
Rear rim size MT 5.50-17"
Rear tyre 180/55 - ZR 17
Type of tyre Radial tubeless tyre
Front brake Hydraulic with 2 calipers
Rear brake Hydraulic with 1 caliper
Engine Type Twin-cylinder 4-stroke Otto-cycle engine
Bore and stroke 94 x 71.5 mm
Displacement 992 cu cm
Compression ratio 11.3 ± 0.5:1
Max. power at crankshaft: 75 kW - 102 HP at 8,750 rpm
Max. crankshaft torque: 93 Nm - 9.5 kgm at 7,250 rpm
Max. engine speed: 9,500 rpm
Timing system Toothed belt drive with single overhead cam,
3 valves per cylinder with 6 rockers in
desmodromic system.
Lubrication system Forced lubrication by pump; cooler
Oil pump type Gear pump
Cooling system Liquid cooling
Air filter One filtering element
Crankshaft type Enbloc
Cylinders "L" at 90°
