Keysight x-series Programmer's Reference

3 VMA Mode
3.8 ACP Measurement
Conditions Results
# Item Unit, if any
5 Lower offset A - relative power dB
6 Lower offset A - absolute power dBm
7 Upper offset A - relative power dB
8 Upper offset A - absolute power dBm
9 Lower offset B - relative power dB
10 Lower offset B - absolute power dBm
11 Upper offset B - relative power dB
12 Upper offset B - absolute power dBm
... ...
When "Max Num of Offsets" on page 1285 is 6, returns 28 results (Offset A-F: 28 = 4 +
4*6) and when set to 12, returns 52 results (Offset A-L: 52 = 4 + 4 * 12)
If any result is not available, -999.0 is returned
This trace includes only outer offset results and their reference value(s)
All other Modes and Power Ref
settings
For the trace specified by "Measure Trace" on page 1755, returns comma-separated
scalar results in the following order:
# Item Unit, if any
1 0.0
2 Total carrier power dBm
3 0.0
4 Reference power dBm
5 Lower offset A - relative power dB
6 Lower offset A - absolute power dBm
7 Upper offset A - relative power dB
8 Upper offset A - absolute power dBm
9 Lower offset B - relative power dB
10 Lower offset B - absolute power dBm
11 Upper offset B - relative power dB
12 Upper offset B - absolute power dBm
... ...
When "Max Num of Offsets" on page 1285 is 6, returns 28 results (Offset A-F: 28 = 4 +
4*6) and when set to 12, returns 52 results (Offset A-L: 52 = 4 + 4 * 12)
If any result is not available, -999.0 is returned
For SA Mode, the values are in the current Y Axis Unit of the instrument
1159 Vector Modulation Analyzer Mode User's &Programmer's Reference

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
