Keysight x-series Programmer's Reference

3 VMA Mode
3.8 ACP Measurement
** RF BW = BWchannel,CA
which is defined in each 3GPP standard, regardless of
“Measure Carrier” for the uppermost and the lowermost carriers being Enabled or
Disabled. When the Number of Component Carrier = 1, RF BW = BW
channel
= 2 x
F
offset,RAT
** sub-block (bandwidth) = BW
channel,block
which is defined in each 3GPP standard,
regardless of “Measure Carrier” for the uppermost and the lowermost carriers being
Enabled or Disabled. When the Number of Component Carrier within each sub-
block = 1, sub-block (bandwidth) = BW
channel
= 2 x F
offset,RAT
.
See "Diagrams for Offset Freq Define" on page 1255.
Modes other than MSR, LTEAFDD, LTEATDD, 5G NR
Remote
Command
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:TYPE CTOCenter | CTOEdge | ETOCenter |
ETOEdge
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:TYPE?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:OFFS:TYPE ETOC
:ACP:OFFS:TYPE?
Notes Some Modes do not support Offset subopcode 2. In those cases, commands with subopcode 2 are
accepted without error but ignored
Preset
CTOCenter
State Saved Saved in instrument state
Range
CTOCenter|CTOEdge|ETOCenter|ETOEdge
Mode: MSR, LTEAFDD, LTEATDD
Remote
Command
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:TYPE CTOCenter | CTOEdge | ETOCenter |
ETOEdge
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:TYPE?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:OFFS:TYPE ETOC
:ACP:OFFS:TYPE?
Preset
CTOCenter
State Saved Saved in instrument state
Range
CTOCenter|CTOEdge|ETOCenter|ETOEdge
Vector Modulation Analyzer Mode User's &Programmer's Reference 1254
