3 VMA Mode
3.9 SEM Measurement
Mode Values
LTEATDD MHz,40 MHz, 40 MHz, 40 MHz | 15.00 kHz,1.5 MHz, 5.5 MHz, 6.5 MHz, 10 MHz,
20MHz, 20MHz, 20MHz, 20MHz, 20MHz, 20MHz, 20MHz
5G NR 50 kHz, 5.05 MHz, 10.5 MHz, 40.00 MHz, 100 MHz, 100 MHz, 100 MHz, 100
MHz, 100 MHz, 100 MHz, 100 MHz, 100 MHz | 15.00 kHz, 1.5 MHz, 5.5 MHz,
100.50 MHz, 105.00 MHz, 100 MHz, 100 MHz, 100 MHz, 100 MHz, 100 MHz,
100 MHz, 100 MHz
When the max number of offsets is 14 in these modes, the preset value of Offset G ~ N is the same as
the Offset F value
WLAN Mode: See the table of "WLAN Mode Presets" on page 1490 below
When the max number of offsets is 6:
Mode Values
SA
ON, ON, ON, ON, ON, OFF
WCDMA
ON, ON, ON, ON, ON, OFF | ON, ON, ON, ON, OFF, OFF
When the max number of offsets is 12 in these modes, the preset value of Offset G ~ L is the same as
the Offset F value
MSR
ON, ON, ON, ON, ON, OFF, OFF, OFF, OFF, OFF, OFF, OFF | ON,
ON, ON, ON, ON, OFF, OFF, OFF, OFF, OFF, OFF, OFF
LTEAFDD,
LTEATDD
ON, ON, ON, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF |
ON, ON, ON, ON, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF
5G NR
ON, ON, ON, ON, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF |
ON, ON, ON, ON, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF
When the max number of offsets is 14 in these modes, the preset value of Offset G ~ N is the same as
the Offset F value
Mode Values
WLAN See the table of "WLAN Mode Auto Function Presets" on page 1492 below
State Saved Saved in instrument state
Saved in instrument state
Min/Max 0 Hz/Depends on instrument maximum frequency
Always Offset Stop Freq - 100 Hz
WLAN Mode Presets
Radio Std Presets
802.11a/g
(OFDM/DSSS-
OFDM)/802.11n
(20MHz)
9 MHz, 11 MHz, 20 MHz, 30 MHz, 40 MHz, 216 MHz, 216 MHz, 216 MHz,
216 MHz, 216 MHz, 216 MHz, 216 MHz, 216 MHz, 216 MHz
Vector Modulation Analyzer Mode User's &Programmer's Reference 1490
