Keysight x-series Programmer's Reference

3 VMA Mode
3.1 Digital Demod Measurement
Parameter DVB-S2X 64-APSK
Code Rate 7/9
DVB-S2X 64-APSK
Code Rate 128/180 (32/45)
DVB-S2X 64-APSK
Code Rate 132/180 (11/15)
Info BW 25 MHz 25 MHz 25 MHz 25 MHz 25 MHz 25 MHz
Symbol Rate 10 MHz 10 MHz 10 MHz 10 MHz 10 MHz 10 MHz
Meas Filter Root Raised
Cosine
Root Raised
Cosine
Root Raised
Cosine
Root Raised
Cosine
Root Raised
Cosine
Root Raised
Cosine
Ref Filter Raised
Cosine
Raised
Cosine
Raised
Cosine
Raised
Cosine
Raised
Cosine
Raised
Cosine
Filter Alpha 0.35 0.35 0.35 0.35 0.35 0.35
Points /
Symbol
5 5 5 5 5 5
Meas Interval 90 symbols 180 symbols 90 symbols 180 symbols 90 symbols 180 symbols
Search Length 3.3552 msec 3.3552 msec 3.3552 msec 3.3552 msec 3.3552 msec 3.3552 msec
Burst Search Off NA Off NA Off NA
Sync Search On NA On NA On NA
Parameter DVB-S2X 128-APSK
Code Rate 135/180 (3/4)
DVB-S2X 128-APSK
Code Rate 140/180 (7/9)
DVB-S2X 256-APSK
Code Rate 116/180 (29/45)
Segments Segment1 Segment2 Segment1 Segment2 Segment1 Segment2
Modulation
Format
QPSK
(Custom IQ)
64-APSK
(Custom IQ)
QPSK
(Custom IQ)
64-APSK
(Custom IQ)
QPSK
(Custom IQ)
64-APSK
(Custom IQ)
Info BW 25 MHz 25 MHz 25 MHz 25 MHz 25 MHz 25 MHz
Symbol Rate 10 MHz 10 MHz 10 MHz 10 MHz 10 MHz 10 MHz
Meas Filter Root Raised
Cosine
Root Raised
Cosine
Root Raised
Cosine
Root Raised
Cosine
Root Raised
Cosine
Root Raised
Cosine
Ref Filter Raised
Cosine
Raised
Cosine
Raised
Cosine
Raised
Cosine
Raised
Cosine
Raised
Cosine
Filter Alpha 0.35 0.35 0.35 0.35 0.35 0.35
Points /
Symbol
5 5 5 5 5 5
Meas Interval 90 symbols 180 symbols 90 symbols 180 symbols 90 symbols 180 symbols
Search Length 3.3552 msec 3.3552 msec 3.3552 msec 3.3552 msec 3.3552 msec 3.3552 msec
Burst Search Off NA Off NA Off NA
Sync Search On NA On NA On NA
Parameter DVB-S2X 256-APSK
Code Rate 124/180 (31/45)
DVB-S2X 256-APSK
Code Rate 128/180 (32/45)
DVB-S2X 256-APSK
Code Rate 135/180 (3/4)
Segments Segment1 Segment2 Segment1 Segment2 Segment1 Segment2
Modulation
Format
QPSK
(Custom IQ)
64-APSK
(Custom IQ)
QPSK
(Custom IQ)
64-APSK
(Custom IQ)
QPSK
(Custom IQ)
64-APSK
(Custom IQ)
319 Vector Modulation Analyzer Mode User's &Programmer's Reference
