Keysight x-series Programmer's Reference

3 VMA Mode
3.1 Digital Demod Measurement
Remote
Command
:CALCulate:DDEMod:TRACe:SEARch:TIME:LENGth <time>
:CALCulate:DDEMod:TRACe:SEARch:TIME:LENGth?
Example
:CALC:DDEM:TRAC:SEAR:TIME:LENG 1.0 ms
:CALC:DDEM:TRAC:SEAR:TIME:LENG?
Notes The align Reference, Offset and Interval determine the trace alignment region, and if the region is out of
the acquisition data range, the trace will stop updating, and a trace indicator “DATA?” (which means
“Data is questionable relative to current setup.”) will be displayed at the top right of the graph
Preset 1 ms
State Saved Saved in instrument state
Min 0.0 s
Max 1.0e6 s
407 Vector Modulation Analyzer Mode User's &Programmer's Reference

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
