Switch 2 Configuration (SISPM1040-384-LRT-C)
VLANs Port 3 Trunk Tag All 5,20
Port 4 Trunk Tag All 5,10
Port 5 Trunk Tag All 5,10,20
STP Port 3 Disable
Port 4 Disable
Port 5 Disable
MEPs Instance Port VLAN MAC MEP ID Peer MAC Peer MEP ID
1 3 20 00-40-C7-1C-C7-2F 3 00-C0-F2-53-F0-BA 8
2 4 10 00-C0-F2-49-39-60 4 00-C0-F2-49-39-5F 1
3 5 10 00-40-C7-1C-C7-31 9 00-C0-F2-53-EF-FE 10
Note: All MEPs are programed the same under the Functional Configuration
Continuity Check
Check Enable – Priority: 7 – Frame rate: 1f/sec
APS Protocol
Check Enable – Priority: 7 – Cast: Multi – Type: R-APS
ERPS
ERPS ID Port 0 Port 1 Port 0 SF Port 1 SF Port 0 APS Port 1 APS Ring RPL Port
VLAN
1 3 2 3 2 3 2 Major Neighbor 1
5
2 1 0 1 0 1 0 Sub Neighbor 0
5
Interconnect Yes, Major 1
