Xerox Phaser 6360 Service Manual

Phaser 6300/6350/6360 Color Laser Printer Service Manual 3-7
Error Messages and Codes
Consumable/Routine Maintenance Item Errors (Continued)
Install or Lock [C][M][Y][K] Toner Cartridge 208, 209, 210,
211
3-41
Install or Reseat Imaging Unit 212 3-33
Install or Reseat Transfer Roller 213 3-35
Install or Reseat Fuser 214 3-38
Remove Ribbon from [C][M][Y][K] Toner Cartridge;
Unlock And Lock Cartridge To Clear
215, 216, 217,
218
3-45
Metered Toner is not Enabled 223 3-54
Tray and Media Errors
Insert Tray 2
Insert Tray [3][4][5]
160
161, 162, 163
3-55
3-56
Out of Paper Load Tray 1(MPT) with [size] [type]
Out of Paper Load Tray [2][3][4][5] with [size] [type]
165
166, 167, 168,
169
3-58
3-59
Manual Feed [size] [type] 170
Output Tray is Full, Unload Paper (Unload Output Tray) 191 3-61
Media Mismatch Errors
Wrong Paper Size Load Tray 1 (MPT) with [size] [type]
Wrong Paper Size Load Tray 2 with [size] [type]
Wrong Paper Size Load Tray [3][4][5] with [size] [type]]
176
177
178, 179, 180
3-62
3-63
3-64
Paper Not Available Load Tray 1(MPT) with [size] [type]
Paper Not Available Load Tray 2 with [size] [type]
Paper Not Available Load Tray [3][4][5] with [size] [type
186
187
188, 189, 190
3-62
3-63
3-64
Configuration Errors
Invalid Configuration Card _ 3-65
Configuration Card Missing _ 3-65
Fatal Errors
Laser Failure [code] 7, 8, 9, 10, 11 3-67
Density Sensor Failure [code] 13, 14, 15, 16 3-68
Fuser Failure [code]
Fuser Failure 44
Fuser Failure [code]
40, 41, 42, 43
44
45, 46, 47
3-69
3-70
3-71
Fuser Fan Failure 50 3-72
Rear Fan Failure 51 3-73
Fan Failure 52 3-75
Power Supply Fan Failure (LVPS Fan) 53 3-74
Fuser Firmware Failure 76 3-76
Error Message Summary (Continued)
Control Panel Message
Code Go to Page

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
