8-34 Phaser 6300/6350/6360 Color Laser Printer Service Manual
Service Parts Disassembly
Low Paper Sensor Actuator (PL3.3.14)
1. Remove the Upper Chute (page 8-33).
2. Release the hook of the Upper Chute that secures the Low Paper Sensor
Actuator, and move the actuator in the direction of the arrow (2) to
remove.
Replacement Note
While holding the Upper Chute, insert the flag downward from the top.
s6360-150
