1-10 Phaser 6300/6350/6360 Color Laser Printer Service Manual
General Information
Maintenance Items
A maintenance item is a printer part or assembly that has a limited life, and
requires periodic replacement.
o
e
The 6360 model Fuser is different than the Fuser used in the 6300/6350
models. Also for 6360 models, two Envelope Feed Rollers have been
added to the Tray 1 (MPT) shaft.
1. Transfer Roller 3. Fuser
2. Imaging Unit 4. Feed Rollers
3
4
s6360-016
21
