Phaser 6300/6350/6360 Color Laser Printer Service Manual 8-9
Service Parts Disassembly
Print Engine Disassembly
Print Engine disassembly is presented in the following procedures organized
in the following categories:
■ Covers
■ Tray s
■ Feeders
■ Retard and Registration
■ Input and Output Chute Assemblies
■ Xerographics
■ Development
■ Drive
■ Electrical
For convenience, it is recommended that you remove the Top Cover, Imaging
Unit, and trays and place them where they do not interfere with the repair.
(Note that servicing can be done with these parts in place depending on the
location of the procedure being performed.) Also, cover the exposed rollers of
the Developer Assemblies with a sheet of paper or other similar material to
avoid the transfer of Toner to clothing or other parts of the printer.
