Xerox Phaser 6360 Service Manual

Phaser 6300/6350/6360 Service Manual 10-9
Wiring Diagrams
1100-Sheet Feeder Plug/Jack Designators
1000-Sheet Feeder Plug/Jack Designators
P/J Coordinates Remarks
Upper Tray
80 I-303 Connects the Upper OPTFDR Board and SIZE2 Harness.
81 J-303 Connects the Upper OPTFDR Board and LOWP Harness.
82 J-303 Connects the Upper OPTFDR Board and Drive Assembly.
83 J-303 Connects the Upper OPTFDR Board and OPFREC2 Harness.
84 J-303 Connects the Upper OPTFDR Board and OPF23 Harness.
85 J-303 Connects the Upper OPTFDR Board and OPFDR2 Harness.
86 J-303 Not Connected
172 G-306 Connects to Print Engine or Option Tray Module
821 H-307 Connects the Paper Size Switch and SIZE2 Harness.
822 G-307 Connects the No Paper Sensor and OPFDR2 Harness.
823 F-307 Connects the Low Paper Sensor and LOWP Harness.
824 H-308 Connects the Feed Solenoid and OPFDR2 Harness.
825 F-308 Connects the Turn Clutch and OPFDR2 Harness.
Lower Tray
80 I-312 Connects the Lower OPTFDR Board and SIZE2 Harness.
81 J-311 Connects the Lower OPTFDR Board and LOWP Harness.
82 J-312 Not Connected
83 J-312 Connects the Lower OPTFDR Board and OPF23 Harness.
84 J-311 Not Connected
85 J-312 Connects the Lower OPTFDR Board and OPFDR2 Harness.
86 J-312 Not Connected
821 H-309 Connects the Paper Size Switch and SIZE2 Harness.
822 G-308 Connects the No Paper Sensor and OPFDR2 Harness.
823 F-308 Connects the Low Paper Sensor and LOWP Harness.
824 H-309 Connects the Feed Solenoid and OPFDR2 Harness.
825 F-310 Connects the Turn Clutch and OPFDR2 Harness.

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
