9-64 Phaser 6300/6350/6360 Color Laser Printer Service Manual
Parts List
Harness Kit
Two versions of the Harness Kit are available. For 6300/6350 models, use P/N
116-2040-00. For 6360 models use P/N 604K38500.
Harness Kit Contents - 116-2040-00 or 604K38500
Part Reference Name/Description Quantity
PL3.2.11 Harness Assy OPFPLG (J17-P171) 1
PL3.3.22 Harness Assy FDR (J47-J471,J472,J473,P474) 1
PL4.1.21 Harness Assy FRONTCLH (J19-J191,J192) 1
PL5.2.28 Harness Assy FSR/ADC (J36-J136,J162,J361) 1
PL5.2.30 Harness Assy TNRFULL/FSR (J52-J142,J521) 1
PL5.3.28 Harness Assy FRONT/DUP (J13-P132, J133, J134,
J135, P501)
1
PL7.2.18 Harness Assy TNR (J51-J342, P511, P512, P513,
P514, J701,J702,J703,J704)
1
PL10.1.1 Harness Assy 24V (J60-J163) 1
PL10.1.2 Harness Assy LV (J61-J165) 1
PL10.1.3 Harness Assy LV RPG (J164-J311) 1
PL10.1.4 Harness Assy TMP (J24-J231) 1
PL10.1.5 Harness Assy HVPS (J16-J141) 1
PL10.1.6 Wire Assy BTR (J138-J139) 1
PL10.1.7 Wire Assy Regi (J137-J140) 1
PL10.1.8 Harness Assy EEPROM (J191-J1911) 1
PL10.1.9 Harness Assy FAN/PHD/MOT (J48-J481, J482, J484,
J491)
1
PL11.1.6 Harness Assy OPFREC (J83-P171) 1
PL12.3.1 Harness Assy OPFREC2 (J83-J172) 1
