Xerox Phaser 6360 Service Manual

1-12 Phaser 6300/6350/6360 Color Laser Printer Service Manual
General Information
Life ratings are based on A-size sheets at 5% coverage. Imaging Unit life
ratings are based on average 5 page job length.
Specifications
Memory Specifications
Electrical Specifications
Toner Cartridges Print Life
Black-Capacity
Color Capacity
Metered (PagePack) Capacity (all colors)
9000 standard, 18,000 high capacity
5000 standard, 12,000 high capacity
18,000 high capacity
Maintenance Items
Imaging Unit 35,000
Fuser 100,000
Transfer Roller and Waste Box 35,000
Feed Roller Kit up to 100,000
Long-Life Maintenance Kit up to 300,000
Characteristic Specification
Minimum RAM 256 MB
Maximum RAM 1 GB
Supported RAM SODIMM 200-pin module of 256 or 512 MB. All combinations are
allowed for configurations of 256, 512, 768 MB, and 1 GB.
NVRAM Single chip of either PPROM or StrataFlash 16 MB
Characteristic Specification
Primary line
voltages
110-127 V Printer - (90 - 135 V) 13 amp circuit
220-240 V Printer - (198 - 254 V) 7-8 amp circuit
Primary line
voltage
frequency
range
100-120 V Printer - 50/60 Hz + 3
Hz
220-240 V Printer - 50/60 Hz + 3
Hz
NOTE Power the printer directly
from the wall outlet. Do not
use “Power Strips” as they
may limit available current.
In-rush
Current
100A, and 10m sec (half cycle) or less. at rated voltage: ±10%
Power
consumption
at rated
voltage input
Mode
Print Mode
Ready Mode
Sleep Mode
Condition
Maximum
Fuser On
Fuser Off
100/120 VAC
1300 W or less
180 W or less
45 W or less
220/240 VAC
1300 W or less
180 W or less
45 W or less

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
