Xerox Phaser 6360 Service Manual

Phaser 6300/6350/6360 Color Laser Printer Service Manual 9-61
Parts List
Service Kits
Service kits are available as an easy means to obtain spare parts normally
associated with larger assemblies. The following tables list each kit’s contents.
Feed Roller Kit
The Feed Roller Kit provides replacements for the Paper Pick and Retard
Roller Assemblies.
Spring Kit
Two versions of the Spring Kit are available. For 6300/6350 models, use P/N
116-2031-00. For 6360 models use P/N 604K38480.
Feed Roller Kit Contents - 604K25823
Part Reference Name/Description Quantity
PL2.1.12 Universal Retard Roller Assembly 1
PL3.3.18 Feed Rollers 2
071-0942-00 Installation Instructions 1
Spring Kit Contents - 116-2031-00 or 604K38480
Part Reference Name/Description Quantity
PL3.3.10 Feed Spring H 2
PL4.1.2 Registration Roller Spring 1
PL5.1.6 Link Spring 1
PL5.2.3 Fuser Lock Lever Spring 1
PL5.2.7 Diode Spring F 1
PL5.2.12 Latch Spring 1
PL5.2.18 CTD (ADC) Sensor Spring 1
PL5.2.22 DTC Bias Spring 1
PL5.3.4 IDT1-1 Bias Spring 1
PL5.3.8 MPT Feed Spring 1
PL5.3.11 MPT N/F Spring 1
PL5.3.33 Earth Out2 Spring 1
PL5.3.34 MPT No Paper Sensor Actuator Spring 1
PL5.4.3 Exit Pinch Roller Springs 2
PL5.4.14 Duplex Jam Sensor Actuator Spring 1
PL6.1.4 Stopper Lever Release Spring 1

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
