Xerox Phaser 6360 Service Manual

Phaser 6300/6350/6360 Color Laser Printer Service Manual 3-39
Error Messages and Codes
Replace Fuser
The Fuser Life counter indicates that the Fuser has reached its end of life.
Fuser replacement is necessary to avoid print quality problems.
N
o
t
e
There is no hard stop associated with the Replace Fuser message.
Applicable Status Code:
Code 207: Replace Fuser
Initial Actions:
■ Print the Supplies Usage page to verify remaining life and Fuser install
date.
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Cycle power to the printer.
Does the error persist?
Go to Step 2. Complete
2 Check the Fuser for damage.
Is the Fuser damaged?
Replace the Fuser,
then cycle power.
Go to Step 3.
3 Check Fuser resistance.
1. Remove the Fuser.
2. Disconnect J361.
3. Is the resistance between P361-B5
<=> P361-B4 less than 400KΩ?
4. Is the resistance between P361-B5
<=> P361-B4 less than 7MΩ?
Go to Step 4. Replace the
Fuser
(
page 8-68).
4 Check all pins on the FSR/ADC Harness
PL5.2.28 for continuity.
1. Disconnect P/J36 and J361.
2. Check continuity between J36 <=>
J361.
Replace the
Engine Control
Board
(
page 8-106).
Replace the
FSR/ADC
Harness.

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
