8-18 Phaser 6300/6350/6360 Color Laser Printer Service Manual
Service Parts Disassembly
Right Front Cover (PL1.1.22)
1. Open Door A.
2. Remove the screw (self-tapping, plastic 10 mm) that secures the Right
Front Cover.
3. Open Door A fully, and with Door B partially opened, release the 2 hooks
to remove the Right Front Cover.
s6360-132
