Xerox Phaser 6360 Service Manual

A-12 Phaser 6300/6350/6360 Color Laser Printer Service Manual
Reference
6300/6350 Service Diagnostics Menu Map
Phaser® 6300/ 6350 Service Diagnostic Menu Map
Print Service Menu Map Prints a service diagnostics Sensor/ Switch Tests - cont'd-
menu map.
Tray 3 No Paper Sensor
Tray 4 No Paper Sensor
General Status
Provides the following print engine status
Tray 5 No Paper Sensor
Status. Transfer Roller Toner Full Sensor
Engine Board ROM Version:<Version> Image Unit Installed/ Not Installed
Printer configuration Fuser Fan Rotation Sensor
Ambient Temp/ Humidity Rear Fan Rotation Sensor
Fuser Temperature Motor Rotation Sensor(s) Main, Developer, Fuser
Fault History ADC (CTD) Sensor
Fuser NC Sensor
Test Prints
Prints Test Prints stored in the MCU.
Fuser STS Sensor
The prints are used by the service personnel to Fuser NC Sensor Amplifier
identify, repair, and validate the operability of the printer. Fuser Temp Compensation
Blank Page Print
Standard Test Print
Clutch Tests
Tests the functionality of the clutches by giving the
Custom Test Print service personnel the ability to energize/ de-energize one clutch at
Current Custom Test Print Setup a time.
Custom Test Print Parameters Registration Clutch
Tray 1 (MPT) Turn Clutch
Motor/ Fan Tests
Tests the functionality of
Tray 3 Turn Clutch
motors and fans by giving service personnel the ability to Tray 4 Turn Clutch
energize/ de-energize the motor and fans one at a time. Tray 5 Turn Clutch
Main Motor
Duplex Motor
Solenoid Tests
Tests the functionality of the solenoids by giving the
Fuser Motor service personnel the ability to energize/ de-energize one solenoid at
Developer Motor a time.
HCF/ LTA Motors 1 & 2 Tray 1 (MPT) Feed Solenoid
Toner Motors (Y) (M) (C) (K) Tray 2 Feed Solenoid
Rear Fan Tray 3 Feed Solenoid
Fuser Fan Tray 4 Feed Solenoid
Tray 5 Feed Solenoid
Sensor/ Switch Tests
Tests the functionality of sensors
and switches by giving service personnel the ability to
Maintenance
Cleans the IDT rollers within the Imaging Unit
input actuation and state changes of all sensors and switches. Clean the Imaging Unit IDT Rollers
Interlock Switch
Registration Sensor
NVRAM Access
This menu lets you read, set or reset the following
Exit Sensor values.
Duplex Sensor PostScript NVRAM Reset
Full Stack Sensor MCU NVRAM Store/ Restore
Toner Low Sensors (B) (C) (M) (Y) Toner Install Dates
Black Toner Cart Present Switch Toner CRUM Check
Cyan Toner Cart Present Switch CRU Life Reset
Magenta Toner Cart Present Switch CRU Life Read
Yellow Toner Cart Present Switch
Black Toner CRUM Sensor
IP Controller diagnostics
Tests the basic functionality of the
Cyan Toner CRUM Sensor the IP Controller board.
Magenta Toner CRUM Sensor RAM Read/ Write Test
Yellow Toner CRUM Sensor
Tray 2 Low Paper Sensor
Exit
Exits service diagnostics and reboots the printer.
Tray 3 Low Paper Sensor
Tray 4 Low Paper Sensor For Authorized Service Personnel Use Only
Tray 5 Low Paper Sensor The Service Menu functions are to be used by Xerox service
Tray 1 (MPT) No Paper Sensor personnel and authorized service providers only. The printer can
Tray 2 No Paper Sensor damaged by the improper use of the built-in service tests.

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
