Phaser 6300/6350/6360 Color Laser Printer Service Manual 8-135
Service Parts Disassembly
Optional 550-Sheet Feeder Disassembly
Docking (PL11.1.1)
Caution
Lifting the printer requires two people. Use care when removing the
printer from the Feeder.
1. Remove Tray 2.
2. Remove four screws that secure the Tray 3 Feeder to the printer.
3. Lift the printer from the Tray 3 Feeder.
s6360-225
