Xerox Phaser 6360 Service Manual

Phaser 6300/6350/6360 Color Laser Printer Service Manual 9-3
Parts List
Using the Parts List
Only those parts listed with part numbers are available for order. Parts listed
without part numbers are only available as part of a parent assembly or
Service Kit.
1. ID No.: The item number reference to the parts list diagram.
2. Part Number: The material part number used to order specific parts.
Note
Parts specific to a particular model are listed as shown in this
example:
Alphanumeric part numbers (054K38040) are either 6360-unique, as
indicated above, or common for all models. 6300/6350-unique part
numbers use the numeric, hyphenated form (116-1989-00).
3. Name/Description: Name of the part and number supplied per order.
4. Parts throughout this manual are referenced PL#.#.#; For example,
PL3.1.10 means the part is item 10 of Parts List 3.1.
5. In the exploded view diagrams, a black triangle preceding a number
followed by a parenthetical statement indicates the item is a parent
assembly, made up of the parts listed in parentheses and enclosed by a
dashed line.
6. The notation “(with X~Y)” following a part name indicates an assembly
includes components X through Y. For example, “1 (with 2~4)” means
assembly number 1 consists of parts 2, 3, and 4.
7. The notation “J1<>J2 and P2” is attached to a wire harness. It indicates
that connector Jack 1 is attached to one end of the wire harness and
connector J2 is attached to the other end that is plugged into P2.
ID No Part Number Name/Description
1. 116-1989-00
054K38040
Chute Assy In (with 2~30), (6300/6350)
Chute Assy In (with 2~31), (6360)
Legend:
Identifier Meaning
C C-ring
E E-ring
KL K-clip
S Screw

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
