Xerox Phaser 6360 Service Manual

6-2 Phaser 6300/6350/6360 Color Laser Printer Service Manual
Adjustments and Calibrations
Calibrations
Color Calibration
Color calibration procedures adjust the printer for optimal color output. Color
settings may need adjustment:
■ On initial printer setup.
■ When Toner Cartridges and Imaging Units are replaced.
■ When the printer environment changes.
■ If the printer has been stored for some time.
■ If the printer has not received significant use.
There are two procedures; lighten/darken colors and balance colors.
If the overall image appears either too light or dark, use the lighten/darken
colors procedure. If a finer adjustment of the primary colors, cyan, magenta
and yellow, is needed, continue with the balance colors procedure.
Print the Color Calibration Colors Tutorial page from the printer’s Control
Panel Troubleshooting --> Print Quality Problems menu and follow the
instructions detailed on the page.
Margin Calibration
The Calibrate Margins menu allows you to adjust the printer’s imaging area
relative to the edges of the paper. The imaging area is shown as a dashed
rectangle on the front side of the print, the printer will not print outside this
rectangle. The dashed rectangle should line up with the solid rectangle
printed on the back side of the page. Hold up to strong light for verification.
Print the Calibrate Margins page for the appropriate tray from the
Troubleshooting --> Print Quality Problems menu and follow the
instructions detailed on the page.

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
