Phaser 6300/6350/6360 Color Laser Printer Service Manual 8-13
Service Parts Disassembly
Control Panel (PL1.1.5)
1. Remove the Front Cover (page 8-12).
2. Release the 2 hooks that secure the Control Panel to the Front Cover.
s6360-126
Control Panel
Front Cover
