Theory of Operation
Tray 3 Feeder
N
o
t
e
The Tray 2 Paper Pick Assembly has a different part number than the 550-
Sheet Feeder’s Paper Pick Assembly.
s6360-073
Turn Roller
Feed Roller
Turn Clutch
No Paper Sensor
Feed Solenoid
Paper Size Switch
Low Paper Sensor
