10-2 Phaser 6300/6350/6360 Service Manual
Wiring Diagrams
Plug/Jack Locator Diagrams
The P/J Locator diagrams show the location of primary connections within the
printer. and optional sheet feeders. Use these illustrations to locate
connections called out in the troubleshooting procedures presented in
Sections 3, 4, and 5.
To find the location of a Plug or Jack:
1. Locate the P/J connector designator in the first column of the table.
2. With this information, go to the map listed in the second column.
3. Use the coordinates to quickly locate the connection indicated on the map
with its P/J designation number.
Print Engine Plug/Jack Designators
Print Engine Plug/Jack Designators
P/J Map Coordinates Remarks
13 3 H-143 Connects the Engine Control Board and FRONT/DUP
Harness.
14 3 G-142 Connects the Engine Control Board and Image Processor
Board.
15 3 F-142 Connects the Engine Control Board and Laser Unit
Harness.
16 3 F-142 Connects the Engine Control Board and HVPS Harness.
17 3 I-143 Connects the Engine Control Board and OPFPLG Harness.
18 3 F-143 Connects the Engine Control Board and REGI SNS
Harness.
19 3 F-143 Connects the Engine Control Board and FRONTCLH
Harness.
20 3 F-143 Not Connected
21 3 E-142 Not Connected
22 3 I-143 Connects the Engine Control Board and OPEPANE2
Harness.
24 3 E-142 Connects the Engine Control Board and TMP Harness.
30 3 E-142 Flash Write
31 3 F-142 Test Print
34 3 F-142 Connects the Engine Control Board and RFID Harness.
36 3 H-143 Connects the Engine Control Board and FSR/ADC Harness.
47 3 H-143 Connects the Engine Control Board and Feeder Harness.
48 3 H-143 Connects Engine Control Board and FAN/PHD/MOT
Harness.
51 3 H-143 Connects the Engine Control Board and Toner Harness.
