Xerox Phaser 6360 Service Manual

1-16 Phaser 6300/6350/6360 Color Laser Printer Service Manual
General Information
Imaging Unit Cleaning Cycle Intervals
Cleaning cycle intervals decrease as the Imaging Unit print volume (life count)
increases. Other factors, such as print mode, environment, temperature,
relative humidity, and area of coverage per print can also increase the
frequency of cleaning cycles irrespective of the Imaging Unit life count.
a. 42 ppm (6360 standard mode)
b. 36 ppm (6350 standard mode)
c. 26 ppm (6300 standard & Enhanced mode)
d. 18 ppm (Most specialty medias and Photo mode)
e. 12 ppm (Thick Card & envelopes)
Environmental Specifications
Imaging Unit
Print Volume
Cleaning Cycle Interval
B/W Speed Color Speed
42
ppm
36
ppm
18
ppm
12
ppm
42
ppm
36
ppm
26
ppm
18
ppm
12
ppm
0 - 5120 108 108 54 39 72 72 52 36 26
5121 - 10240 72 72 36 26 48 48 35 34 17
10241 - 15360 72 72 36 26 48 48 35 34 17
15361 - 20480 72 72 36 26 48 48 35 34 17
20481 - 25600 54 54 27 20 36 36 26 18 13
25601 - 30720 54 54 27 20 36 36 26 18 13
above 30721 54 54 27 20 36 36 26 18 13
Characteristic Specification
Temperature:
Operating
Optimal Print Quality
Range
5
o
C to 32
o
C (41
o
F to 90
o
F)
15
o
-28
o
C (60
o
to 82
o
F)
Storage
12 month maximum
48 hours maximum
Normal: 0
o
C to 35
o
C (32
o
F to 95
o
F), at 15% - 85% RH
Severe: -20
o
C to 40
o
C (-4
o
F to 104
o
F) at 5% - 95% RH
Humidity (RH)
Operating
Optimal Print Quality
Range
15% - 85% RH
20% to 70% RH
Altitude
Operating
Transportation
0 - 3,100 meters (10,170 ft.)
0 - 15,000 meters (30,000 ft.) in pressurized containers.
Acoustic Noise (Lwa)
Idle
Printing
Printer Only With Feeder Option
5.0 B or less 5.0 B or less
6.65 B or less (Full Speed) 7.35 B or less (Full Speed)
6.65 B or less (Half Speed) 7.30 B or less (Half Speed)

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
