8-78 Phaser 6300/6350/6360 Color Laser Printer Service Manual
Service Parts Disassembly
Housing Assembly Bias (PL6.1.7)
1. Remove the Top Main Cover (page 8-11).
2. Remove the Left Front Cover (page 8-19).
3. Remove the Left Side Cover (page 8-15).
4. Remove the HVPS (page 8-111).
5. Remove the 2 wires from the harness guide on the Housing Assembly
Bias.
6. Remove the 4 screws (self-tapping, plastic 10 mm) that secure the
Housing Assembly Bias to the printer and remove.
Replacement Note
The contact springs must protrude through to the inside of the printer.
s6360-195
