Phaser 6300/6350/6360 Color Laser Printer Service Manual 8-55
Service Parts Disassembly
Full Stack Actuator (PL5.4.2)
1. Remove the Front Cover (page 8-12).
2. Bend the middle of the Full Stack Actuator somewhat and remove the left
and right ends from the mounting holes.
s6360-181
To Next Page
