7-4 Phaser 6300/6350/6360 Color Laser Printer Service Manual
Cleaning and Maintenance
Cleaning the Laser Windows
The four laser windows are positioned behind the Developer Frame Assembly.
To clean the windows, remove the Developer Frame Assembly by following
the procedure begining on (
page 8-79), and then gently wiping each window
with a lint free cloth.
Maintenance
RIP (Repair, Inspect, and Prevent) Procedures
Perform these routine maintenance procedures during the course of servicing
the printer.
■ Clean the feed rollers, exit rollers, and guides; replace if necessary.
■ Remove and clean all paper trays.
■ Clean the image density sensor [CTD (ADC) Sensor].
■ Print a Status page, diagnose, and repair any problems as indicated.
■ Check the print engine and image processor firmware version. Update if
necessary.
■ Check cleanliness of interior and exterior, including fans; if necessary
clean (dust or vacuum) these areas.
■ Review proper printer operation using a customer file, if possible. Check
with the customer regarding any special applications they may be
running.
■ Review with the customer all work that was performed; also discuss
proper printer care.
Long-Life Maintenance Kit Installation
The Long-Life Maintenance Kit extends printer life up to 600,000 prints. Install
the Long-Life Maintenance Kit when the printer displays the Replace
Maintenance Kit error message. The Long-Life Maintenance Kit provides
these replacement parts:
■ Developer Assemblies, PL7.1.17~20
■ Registration Roller Assembly, PL4.2.1
■ Retard Roller Assembly, PL4.1.13
■ Tray 1 (MPT) Feed Roller, PL5.3.20
■ Paper Feed Roller Kit, PL2.1.12 and PL3.3.18
Access the Developer Assemblies by removing the Top Main Cover, Right and
Left Side Covers, Door C, the Imaging Unit, and the Developer Frame
Assembly. Use the following steps to install the Long-Life Maintenance Kit.
Caution
Allow adequate time for the Fuser to cool before servicing the printer.

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
