Xerox Phaser 6360 Service Manual

A-6 Phaser 6300/6350/6360 Color Laser Printer Service Manual
Reference
Printer Status Codes
Printer status codes that appear in the Service Usage Profile at line 237, on
the printer Status page, and output by the Diagnostic Fault History utility are
defined in the following table. Refer to the
“Messages, Codes, and
Procedures” on page 3-5 for additional information.
Printer Status Codes
Code Description
7 Laser Failure 7. Laser power failure.
8 Laser Failure 8. Laser Start of Scan error 1.
9 Laser Failure 9. Laser Start of Scan error 2.
10 Laser Failure 10. Laser warm-up error.
11 Laser Failure 11. General Laser Unit error.
13 Density Sensor Failure 13. CTD (ADC) Sensor failure.
14 Density Sensor Failure 14. CTD (ADC) Sensor Toner Density Control signal is
over limit.
15 Density Sensor Failure 15. CTD (ADC) Sensor Toner Density Control signal is at
limit.
16 Density Sensor Failure 16. General CTD (ADC) Sensor error.
40 Fuser Failure 40. Fuser exceeding temperature range.
41 Fuser Failure 41. Fuser below temperature range.
42 Fuser Failure 42. Fuser Temperature Sensor error.
43 Fuser Failure 43. Fuser did not reach warm-up temperature in time.
44 Fuser Failure 44. Fuser heater failure.
45 Fuser Failure 45. Fuser heater regulation failure.
46 Fuser Failure 46. LVPS heater control relay tripped or failed.
47 Fuser Failure 47. General Fuser error.
50 Fuser Fan Failure. Fuser Fan rotation signal error.
51 Rear Fan Failure. Rear Fan rotation signal error.
52 Fan Failure. General Fan error.
53 LVPS Fan Failure. The LVPS Fan has failed.
70 Engine Firmware Failure 70. Fuser temperature firmware error.
71 Engine Firmware Failure 71. Cleaning count firmware error.
72 Engine Firmware Failure 72. NVRAM failure.
73 Engine Firmware Failure 73. NVRAM Checksum error.
74 Engine Firmware Failure 74. ASIC failure.
75 Engine Firmware Failure 75.
76 Fuser Firmware Failure. Fuser NVRAM failure.

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
