Xerox Phaser 6360 Service Manual

Phaser 6300/6350/6360 Service Manual 10-35
Wiring Diagrams
Tray
P/J823
3
OPTFDR 1 Board
PL11.1.9
P/J80
1
2
4
3
Paper Size
Switch
PL11.2.6
OPTION TRAY2 SIZE0 ON(L) +3.3VDC
OPTION TRAY2 SIZE1 ON(L) +3.3VDC
5
SG
NC
OPTION TRAY2 SIZE2 ON(L) +3.3VDC
P/J821
4
3
1
2
Low Paper Sensor
PL11.3.7
2
1
P/J81
1
2
3
PULL UP +3.3VDC
SG
OPTION TRAY2 LOW PAPER ON(L) +3.3VDC
P/J85
1
2
I/L +24VDC
OPTION TRAY2_TURN ON(L) +24VDC
P/J85
3
4
Feed Solenoid
PL11.3.11
P824
2
J824
1
12
I/L +24VDC
OPTION TRAY2 FEED ON(L) +24VDC
P825
2
1
J825
1
2
Turn Roller
Clutch
PL11.3.4
P/J822
3
No Paper Sensor
PL11.3.7
2
1
P/J85
5
6
7
PULL UP +3.3VDC
SG
OPTION TRAY2 NO PAPER ON(H) +3.3VDC
P/J84
1
2
3
4
5
6
7
8
9
10
11
P/J172
10
9
8
7
6
5
4
3
2
1
NC
RXD
TXD
TRY_SNS_2
SG
+3.3VDC
SG
SG
I/L +24VDC
SG
I/L +24VDC
+3.3VDC
Interlock
+24VDC
+3.3VDC
Interlock
+24VDC
Interlock
+24VDC
+3.3VDC
To 1100 Sheet Feeder
s6360-334

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
