8-24 Phaser 6300/6350/6360 Color Laser Printer Service Manual
Service Parts Disassembly
Printer Chassis
Removal of the printer chassis is required to service the following
components:
■ Tray 2 Paper Size Switch
■ Option Feeder Harness
■ Tray 2 Paper Pick Assembly
■ Tray 2 No Paper Sensor and Actuator
Caution
Two people are required to separate the chassis from the Tray 2 Feeder.
1. Remove Tray 2.
2. Remove the Top Main Cover (page 8-11).
3. Remove the Right Side Cover (page 8-14).
4. Remove the Left Side Cover (page 8-15).
5. Remove the Rear Cover (page 8-17).
6. Remove the Feeder Chute (page 8-22).
7. Remove the Front Feeder Frame Cover (page 8-20)
8. Perform steps 1 and 2 of the I/P Board removal procedure (page 8-99).
9. Remove the LVPS Fan Duct.
10. Remove the HVPS (page 8-111).
11. Remove the Temperature/Humidity Sensor Bracket (page 8-110).
12. Unplug connectors (P/J161, 162, 163, 164, and 165) from the LVPS. See
the locator diagram on page 10-6.
