Xerox Phaser 6360

2-50 Phaser 6300/6350/6360 Color Laser Printer Service Manual
Theory of Operation
Drive
The Drive Assembly incorporates a stepper motor to power the gear train as
shown in the following figure.
Idle Gear 21/29
Gear 24
Feeder Drive Assembly
Upper Paper Pick Assembly
Turn Clutch
Turn Roller
Feed Roller
Feed Gear H1
Feed Gear 2
Feed Roller
Gear Idler Feed
Feed Gear 2
Feed Gear H2
s6360-075
Idle Gear 21/29
Lower Paper Pick Assembly
Turn Clutch
Turn Roller
Feed Roller
Feed Gear H1
Feed Gear 2
Feed Roller
Gear 24
Gear Idler Feed
Feed Gear 2
Feed Gear H2
