Xerox Phaser 6360 Service Manual

4-14 Phaser 6300/6350/6360 Service Manual
General Troubleshooting
Paper Size Switch Assembly
Paper size and tray presence is detected by the state of the upper, middle,
and lower switches of the Paper Size Switch. A failed or jammed switch
effects the printer’s ability to accurately detect paper size or the presence of
the paper tray.
Power Supply
LVPS Overcurrent Protection Circuit
This circuit stops all outputs if the 24 VDC, 5 VDC or 3.3 VDC power supply is
shorted. The circuit is reset when the short is removed, the power is turned
off, and then on again.
N
o
t
e
The 5V supply to the Image Processor Board is excluded. This circuit is
protected by a fuse (F101) which if blown, must be replaced.
LVPS Overvoltage Protection Circuit
This circuit stops all outputs if the 24 VDC, 5 VDC or 3.3 VDC power supply
exceeds the specified voltage. The operating point is 32 VDC or more for 24
VDC, 7
VDC or more for 5 VDC, or 6 VDC or more for 3.3 VDC.
N
o
t
e
The circuit resets after a short period of time, approximately 5 minutes,
after the printer power is cycled.
Fan Output Circuit
For the Fan Rear On(H) and Fan LVPS On(H) signals, the output voltage
varies depending on the status of FAN LOW signal and FanStop signal from
the Fan Control circuit on the LVPS (refer to
“Power” on page 10-17).
Paper Size
Switches
Upper Middle Lower
Legal 14" On On On
US Folio (Legal 13)" On On Off
Executive On Off On
B5 On Off Off
A4 Off On On
A5 (for reference, supported in Tray 1(MPT)
only)
Off On Off
Letter Off Off On
No Tray Off Off Off

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
