Page #162 background image
3-62 Phaser 6300/6350/6360 Color Laser Printer Service Manual
Error Messages and Codes
Media Mismatch Errors
Wrong Paper Size or Paper Not Availabe; Load Tray 1 (MPT) with [size][type]
Tray 1 (MPT) Paper Size mismatch error.
Applicable Status Code:
Code 176: Wrong Paper Size; Load Tray 1 (MPT) with [size] [type]
Code 186: Paper Not Available; Load Tray 1 (MPT) with [size] [type]
Initial Actions:
Inspect the tray to ensure that it is free of obstructions, is loaded with
supported media, and the guides are adjusted correctly.
Cycle printer power.
If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack References
Tray 1 (MPT) No Paper
Sensor, PL3.2.5
Paper Size Switch Signals table (page 2-7)
Print Engine Map 1 - P/J Locator (page 10-5)
Print Engine Paper Feed Wiring (page 10-26)
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the Tray 1 (MPT) No Paper
Sensor for evidence of fault or
damage:
Is there any damage?
Replace any
damaged parts.
Go to Step 2.
2 Test the Tray 1 (MPT) No Paper
Sensor
Run the Service Diagnostics Tray 1
(MPT) No Paper Sensor test.
Does the sensor function correctly?
Go to Step 4. Go to Step 3.
3 Check all pins on the FRONT/DUP
Harness for continuity.
1. Disconnect P/J13 and P/J135.
2. Check continuity between
J13<=>J135.
Go to Step 4. Replace the
FRONT/DUP
Harness.
4 Check the No Paper Sensor signal at
the Engine Control Board.
Is there 3.3V at P13-15 when
actuated?
Replace the No
Paper Sensor
(
page 8-47)
Replace the
Engine Control
Board
(
page 8-106).
