Xerox Phaser 6360 Service Manual

Phaser 6300/6350/6360 Service Manual 4-15
General Troubleshooting
+24 VDC Output Stopped By Interlock Switch
Opening Door A or B opens the Interlock Switch. This shuts off the +24 VDC
supplied to the motors, clutches, and solenoids.
AC Power Supply Troubleshooting
DC Power Supply Troubleshooting
N
o
t
e
If an internal short has occurred, the LVPS requires several minutes to
reset.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack References
■ LVPS, PL9.1.6 ■ Print Engine Power Wiring Diagram (page 10-17)
Troubleshooting Procedure Table
Step Action and Questions Yes No
1 Check the voltage at the AC wall outlet.
Is there approximately 110 VAC (or 220 VAC
if the printer is a 220 V configuration) at the
AC wall outlet?
Go to Step 2. Notify the
customer of
improper AC
output from
the outlet.
2 Check the power cord for defects or a loose
connection.
Replace or
reseat the
power cord.
Replace the
LVPS
(
page 8-100).
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack References
■ LVPS, PL9.1.6 ■ Print Engine LVPS and Drive P/J Locator (page 10-6)
■ Print Engine Power Wiring Diagram (page 10-17).
Troubleshooting Procedure Table
Step Action and Questions Yes No
1 Perform the AC power supply
troubleshooting procedure.
Does the problem persist?
Go to Step 2. Complete
2 Turn the AC power Switch Off.
Is the fuse (F101) on the low-voltage
power supply board open?
Replace the LVPS
(
page 8-100).
Go to Step 3.

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
