Phaser 6300/6350/6360 Color Laser Printer Service Manual 8-5
Service Parts Disassembly
N
o
t
e
Names of parts that appear in the removal and replacement procedures
may not match the names that appear in the Parts List. For example, a
part called the Registration Chute Assembly in a removal procedure may
appear on the Parts List as Assembly, Chute REGI. When working on a
removal procedure, ignore any prerequisite procedure for parts already
removed.
Caution
Many parts are secured by plastic tabs DO NOT over Flex or force these
parts. Do not over torque the screws threaded into plastic parts.
Always use the correct type and size screw. Using the wrong screw can
damage tapped holes. Do not use excessive force to remove or install
either a screw or a printer part.
W
arn
i
ng
Unplug the AC power cord from the wall outlet before removing any
printer part.
Notations in the Disassembly Text
■ The notation “(item X)” points to a numbered callout in the illustration
corresponding to the disassembly procedure being performed.
■ The notation “PLX.X.X” indicates that this component is listed in the Parts
List.
■ Bold arrows in an illustration show direction of movement when removing
or replacing a component.
■ The notation “(self-tapping, plastic 10 mm)” or “(metal, 6 mm)” refer to the
type of screw being removed.
N
o
t
e
Notes within disassembly procedures provide information specific to the
replacement step, part or assembly.
Replacement Note
Replacement Notes provide considerations or additional steps
needed for reassembly.
