Phaser 6300/6350/6360 Color Laser Printer Service Manual 2-13
Theory of Operation
Transfer Roller Control
Detecting the Transfer Roller
The CTD (ADC) Sensor is used to detect the presence of the Transfer Roller.
This determination is made whenever power is turned on, or a door is opened
and closed.
If the output of the CTD (ADC) Sensor is greater than the reference value the
controller signals that the Transfer Roller is present. If the sensor output is
lower than the reference, a Fatal Error indicates that the Transfer Roller is not
installed.
If printing is stopped by a jam, a latent image remains on the Transfer Roller.
To prevent a false error, the controller rotates the Transfer Roller a half turn. If
the sensor output remains below the reference, a Transfer Roller missing error
is generated. Otherwise, the sensor output indicates that the Transfer Roller is
present and no additional error is reported.
Detecting Transfer Roller Life
The Transfer Roller consists of a bias transfer roller and a waste toner
recovery space. Transfer Roller end of life occurs when the Toner Full Sensor
detects that the waste toner recovery space is full.
1. Status of the waste toner reservoir is checked:
a. When the power is turned on.
b. When a door is opened and closed.
c. When paper exits the print engine.
2. Transfer Roller is at End of Life warning message is generated when the
Toner Full Sensor detects the waste toner reservoir is full.
3. Replace Transfer Roller error message is generated if the print count and
the toner dispense time are counted and the total count exceeds 15,000
prints.
4. Transfer Roller is at End of Life warning and Replace Transfer Roller error
messages are reset if the Toner Full Sensor does not detect a full waste
toner reservoir when power is turned on, or a door is opened and closed.

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
