Xerox Phaser 6360

Phaser 6300/6350/6360 Color Laser Printer Service Manual 8-117
Service Parts Disassembly
Feeder Chute (PL12.2.7)
1. Remove the tray.
2. Push inward on the concaved sections at the left and the right sides and
swing the Feeder Chute downward.
3. Release the retainer at one end of the Feeder Chute to release the boss
from the Feeder Assembly.
4. Pull the Feeder Chute out, and then down to remove it from the frame.
