Xerox Phaser 6360 Service Manual

1-8 Phaser 6300/6350/6360 Color Laser Printer Service Manual
General Information
Printer Options
Phaser 6300/6350/6360 printer options include:
■ Hard Drive
■ Additional Memory
■ Configuration Card
■ 1100-Sheet Feeder
■ 550-Sheet Feeder
Options are common for all models. However, the Configuration Cards are
unique for each model and configuration.
Hard Drive
A Hard Drive is available to enable the Job Collation, Saved Jobs, Proof,
Personal, and Secure Print options. The Hard Drive installs on the Image
Processor Board with stand-offs and connects to the board with a single data/
power connector. Hard Drive utilization appears on the Configuration page.
Additional Memory
The printer features two slots that accept 256 or 512 MB of high-speed DDR
RAM. All combinations are allowed for 256, 512, 768 MB and 1 GB. Memory
modules must have the following characteristics:
■ DDR PC2700 Memory Standard
■ 200-Pin SODIMM
■ Unbuffered, Non-parity
■ Serial Presence Detect
■ 2.5 Volt
■ CL 2.5
The Startup page and the Configuration page list the amount of RAM installed
in the printer. Installed memory not meeting the above specifications, is
ignored by the printer.
Configuration Card
A Configuration Card identifies the printer configuration, stores shadowed
non-CRUM consumable data, consumable life counts, and network
configuration parameters.

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
