Xerox Phaser 6360 Service Manual

2-14 Phaser 6300/6350/6360 Color Laser Printer Service Manual
Theory of Operation
Toner Control
Toner Cartridge presence is detected by a combination of the Toner Sensor
Actuator and CRUM Reader. Presence of toner in the cartridge is detected by
the No Toner Sensor. These sensors are provided for each toner color
(CMYK), and detection is made for each individually.
No Toner Sensor
The No Toner Sensor located on each Toner Cartridge Holder checks one
color every 3.5 seconds, requiring 14 seconds to detect all four colors. The
sensor detects toner as it’s dispensed from the toner cartridge into the auger
tube.
To prevent false errors resulting from toner obscuring the sensor, a film
attached near the auger in the Toner Cartridge Holder cleans the sensor
surface whenever toner is dispensed. False errors related to toner detection
are avoided by the printer’s internal Toner Presence Control.
Toner Presence Control
1. Checks for toner presence when the power is turned on, or after a door is
opened and closed. Checks every 14 seconds when printing.
2. The "Replace [CMYK] Toner Cartridge" error displays when the counter
on the Customer Replaceable Unit Monitor (CRUM) indicates that the
toner is empty.
3. The "Replace Toner Cartridge” error displays when the No Toner Sensor
detects that a cartridge is empty.
4. When a new Toner Cartridge is installed prior to receipt of a "Replace
Toner Cartridge” error, toner is dispensed for 1.7 seconds. At the next
toner presence control sampling, if the No Toner Sensor detects toner
present, all Toner “Warnings", and "Errors" are reset. When toner is
dispensed and the No Toner Sensor detects toner present three or more
times consecutively, the controller regards this status as "Toner Present".
5. If the No Toner Sensor does not detect toner, toner is dispensed for 1.7
seconds again 5 seconds later. If toner present is not detected after
executing toner dispense three times and if Toner Cartridge dispense time
is 0, the “Remove Ribbon From ‘x’ Cartridge” error displays.

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
