Xerox Phaser 6360 Service Manual

Phaser 6300/6350/6360 Color Laser Printer Service Manual 8-91
Service Parts Disassembly
Toner Cartridge Holder Assembly
Complete removal of the Toner Cartridge Holder Assembly is not required to
access the upper most Laser Unit screw. Use the following procedure to
loosen the assembly and lift it approximately 0.5 inch it to allow access to the
Laser Unit screw without disconnecting the Auger Tubes or removing the
Toner Cartridges.
W
arn
i
ng
Be sure to clean up any residual toner on the Toner Cartridge Holder
Assembly with a dedicated toner vacuum cleaner. Do not clean up toner
with a general-purpose vacuum cleaner to avoid the risk of explosion by
igniting the fine powder. As an additional precaution, be sure to attach a
ground cable to the toner vacuum cleaner to discharge static electricity.
Caution
Take care not to allow toner dust to adhere to the photo sensors located
on the Toner Cartridge Holder Assembly. Toner adhering to the photo
sensors reduces their efficiency and could cause erroneous errors.
1. Remove the Top Main Cover (page 8-11).
N
o
t
e
To control toner spillage, after removing the Top Main Cover, replace the
Toner Cartridges and lock them into place.
2. Remove the Right Side Cover (page 8-14).
3. Remove the Left Side Cover (page 8-15).
4. Remove the Rear Cover (page 8-17).
5. Remove the 2 wires (red) from the harness guide on the CRUM Reader.

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
