Phaser 6300/6350/6360 Color Laser Printer Service Manual A-13
Reference
6360 Service Diagnostics Menu Map
PhaserÆ 6360 Service Diagnostic Menu Map
Print Service Menu Map Prints this menu map and exits
service diagnostics.
General Status
Provides the following print engine status.
Status
Engine Board ROM Version
Printer Configuration
Ambient Temp/Humidity
Fuser Temperature
Fault History
Test Prints Prints Test Prints. Use the prints to identify, repair,
and validate printer operation.
Blank Page Print
Standard Test Print
Custom Test Print
Current Custom Test Print Set-up
Custom Test Print Parameters
Motors/Fans Tests Tests the motors and fans by energizing/
de-energizing one at a time.
Main Motor
Duplex Motor
Fuser Motor
Developer Motor
HCF/LTA Motor 1
HCF/LTA Motor 2
Toner Motor Yellow
Toner Motor Magenta
Toner Motor Cyan
Toner Motor Black
Rear Fan
Fuser Fan
LVPS Fan
Sensor/Switch Tests Test the sensors and switches by
actuation and state changes of all sensors and switches.
Interlock Switch
Registration Sensor
Exit Sensor
Duplex Sensor
Full Stack Sensor
Black Toner (K) Low/Empty Sensor
Cyan Toner (C) Low/Empty Sensor
Magenta Toner (M) Low/Empty Sensor
Yellow Toner (Y) Low/Empty Sensor
Black Toner Cart Present Switch
Cyan Toner Cart Present Switch
Magenta Toner Cart Present Switch
Yellow Toner Cart Present Switch
Black Toner CRUM Sensor
Cyan Toner CRUM Sensor
Magenta Toner CRUM Sensor
Yellow Toner CRUM Sensor
Tray 2 Low Paper Sensor
Tray 3 Low Paper Sensor
Tray 4 Low Paper Sensor
Tray 5 Low Paper Sensor
Sensor/Switch Tests -contíd-
Tray 1 (MPT) No Paper Sensor
Tray 2 No Paper Sensor
Tray 3 No Paper Sensor
Tray 4 No Paper Sensor
Tray 5 No Paper Sensor
Transfer Roller Toner Full Sensor
Image Unit Installed/Not Installed
Fuser Fan Rotation Sensor
Rear Fan Rotation Sensor
LVPS Fan Rotation Sensor
Motor Rotation Sensor Main, Developer, Fuser
ADC (CTD) Sensor
Fuser NC Sensor
Fuser STS Sensor
Fuser NC Sensor Amplifier
Fuser Temp Compensation
Clutch Tests Tests the functionality of the clutches by
energizing/de-energizing one clutch at a time.
Registration Clutch
Tray 1 (MPT) Turn Clutch
Tr ay 2 Tu r n C l u t c h
Tr ay 3 Tu r n C l u t c h
Tr ay 4 Tu r n C l u t c h
Tr ay 5 Tu r n C l u t c h
Solenoid Tests Tests the solenoids by energizing/de-energizing
one solenoid at a time.
Tray 1 (MPT) Feed Solenoid
Tray 2 Feed Solenoid
Tray 3 Feed Solenoid
Tray 4 Feed Solenoid
Tray 5 Feed Solenoid
Maintenance Cleans the Imaging Unit IDT rollers.
Clean Imaging Unit IDT Rollers
NVRAM Access Read, set, or reset these values:
PostScript NVRAM Reset
MCU NVRAM Store/ Restore
Toner Install Dates
Toner CRUM Check
CRU Life Reset
CRU Life Read
IP Controller Diagnostics Tests basic functions of the Image
Processor Controller Board.
RAM Read/Write Test
Exit Exits service diagnostics and reboots the printer.
For Authorized Service Personnel Use Only. Service Menu
functions are to be used by Xerox service personnel and
authorized service providers only. The printer can be damaged by
improper use of the built-in service tests.

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
